Enhanced Black TN (EBTN) |
Graphic Series
Model No. |
Display Format L x W (dots) |
Module Size L x W (mm) |
Viewing Area L x W (mm) |
Backlight Y / N |
Assembly Type |
Duty |
Interface |
CG1212A |
12 x 12 |
56.00 x 65.20 |
52.00 x 52.00 |
Y |
COG |
static |
8-bit |
CG12832A |
128 x 32 |
92.00 x 36.50 |
76.00 x 22.20 |
Y |
COG |
1 / 33 |
I2C |
CG12864D |
128 x 64 |
78.40 x 53.00 |
70.60 x 38.60 |
Y |
COG |
1 / 64 |
Serial |
Character / Digit Series
Model No. |
Display Format Character x Line |
Module Size L x W (mm) |
Viewing Area L x W (mm) |
Backlight Y / N |
Assembly Type |
Duty |
Interface |
CG9161B |
16 x 1 |
102.40 x 24.40 |
99.00 x 14.00 |
Y |
COG |
1 / 8 |
3-line SPI / I2C |
CV4162D |
16 x 2 |
80.00 x 36.00 |
61.00 x 15.80 |
Y |
COB |
1 / 16 |
4-bit / 8-bit |
CV4162E |
16 x 2 |
122.00 x 44.00 |
99.00 x 24.00 |
Y |
COB |
1 / 16 |
4-bit / 8-bit |
CV4162F |
16 x 2 |
80.00 x 36.00 |
61.00 x 15.80 |
Y |
COB |
1 / 16 |
4-bit / 8-bit |
CV4162H |
16 x 2 |
84.00 x 44.00 |
61.00 x 15.80 |
Y |
COB |
1 / 16 |
4-bit / 8-bit |
*More sizes can be available upon your request.
7 Segment Series
Model No. |
Display Format No. of Digits |
Display Size (mm) |
Viewing Area L x W (mm) |
Digit Height (mm) |
Duty |
Backlight Y / N |
Other Description |
V5026 |
4 |
50.80 x 30.50 |
47.00 x 18.80 |
12.7 |
Static |
Y |
1Col + 3Dp |
V5096 |
3 1/2 |
50.80 x 30.50 |
46.70 x 18.80 |
12.7 |
Static |
Y |
Icons + 1Col + 3Dp |
V5952 |
3 1/2 |
50.80 x 30.50 |
47.00 x 18.80 |
12.7 |
Static |
Y |
Icons + 1Col + 3Dp |
V5974 |
6 |
170.00 x 85.00 |
162.00 x 72.00 |
45 |
Static |
Y |
Icons + 2Col + 6Dp |
*More sizes can be available upon your request.
Please contact us for more information
